Product Description
Product Overview
A modern kitchen often needs two separate power connections at the same point: a hardwired supply for the oven, and a socket outlet for a plug-in appliance like a pre-wired induction hob. Traditionally, that required installing two separate wall accessories side by side.
Both outlets are independently controlled, allowing the cooker and socket to be switched off individually without cutting power to both appliances. This allows easy maintenance or isolation for either the hob or the oven without shutting down the entire cooking point.
Key Capabilities
- Universal First-Fix Solution: Connects both hardwired and plug-in appliances to a single plate without choosing between a socket or cooker unit early in the build.
- High Load Rating: 45A connection handles the full capacity requirements of modern electric ovens and hobs.
- Independent Outlet Control: Separate switching for the 45A cooker terminal and 13A socket outlet.
- Standard Back Box Fit: Mounts to a single UK back box (35mm minimum depth recommended, depending on cable gauge).
- Flexible Conductor Terminals: Accommodates large input and output cable gauges for both rigid and flexible wiring styles.
Contractor & Developer Advantage
Halving the required wall accessories per kitchen offers a major installation advantage for landlords, housing associations, and new-build contractors fitting multiple units to the same specification. Consolidating to a single back box significantly speeds up first and second-fix installation time across full residential developments.
Frequently Asked Questions
What is a dual cooker connection unit for?
It combines two separate accessories, a hardwired cooker connection and a 13A switched socket, into a single plate on one back box. Useful wherever a kitchen needs to power both a hardwired oven and a plug-in appliance, a pre-wired induction hob, for example, from the same point rather than fitting two separate accessories side by side.
Can I switch off the oven without cutting power to the socket?
Yes. The two outlets are independently controlled, so the cooker connection and the 13A socket can each be isolated on their own.
What back box does this need?
A standard UK back box, 35mm deep is generally sufficient, though the exact depth needed depends on the size and number of conductors being terminated, particularly if using cable towards the top end of the 16mm² input rating.
What standards does the Stanic Duo comply with?
The cooker connection unit is built to BS 5733, the standard covering cooker connection units generally.
Is this suitable for a plug-in induction hob?
Yes, that's specifically what the socket side is designed for, alongside the hardwired connection for a conventional oven. Both a hardwired appliance and a plug-in one can be powered from the same plate.
