OHME EPOD UNTETHERED SMART CHARGER 7.4KW - OHMEX1GB003

Ohme ePod – 7.4kW Smart Socketed EV Charger – OHMEX1GB003-BL

The Ohme ePod is a compact and discreet smart EV charger offering convenient, cost-effective home charging without taking up unnecessary wall space.

Delivering up to 7.4kW (32A), the ePod can charge an electric vehicle up to eight times faster than a standard three-pin plug. Its universal Type 2 socket lets you connect a suitable charging cable for virtually any make or model of EV.

⚡ Fast 7.4kW Home Charging

Charge your electric vehicle at up to 7.4kW from a single-phase supply, making the ePod ideal for reliable overnight charging at home.

💷 Charge When Electricity Is Cheaper

The Ohme ePod dynamically schedules charging around the cheapest available electricity periods, helping you make the most of off-peak and smart EV tariffs.

It integrates with UK energy providers, including compatible Octopus Energy and OVO smart EV tariffs.

📱 Ohme Smartphone App

Use the Ohme smartphone app to control and monitor charging from your phone.

The app allows you to:

• ✅ Create charging schedules
• ✅ Set charging targets
• ✅ Monitor charging sessions
• ✅ Track estimated charging costs
• ✅ Charge during cheaper tariff periods
• ✅ Receive automatic software updates

Charging can also be controlled directly using the three buttons on the charger.

📶 Built-In 3G/4G Connectivity

The ePod automatically connects through the mobile phone network using its integrated multinetwork SIM card, so it does not rely on the property’s Wi-Fi connection.

Ohme covers the connectivity cost for the first three years.

🔌 Universal Type 2 Socket

The charger features a Type 2 socket compliant with IEC 62196, allowing customers to use a compatible detachable charging cable.

This makes it suitable for virtually any Type 2 electric or plug-in hybrid vehicle.

🛡️ Integrated Safety Protection

Built-in protection provides safe operation while helping simplify installation:

• ✅ Built-in 30mA Type A RCD protection
• ✅ Integrated 6mA DC leakage protection
• ✅ Built-in protective earth neutral fault detector
• ✅ Dynamic load balancing with an optional CT clamp
• ✅ Five-colour LED status indication

Please note: Overcurrent protection is not built into the charger and must be installed separately.

🌧️ Compact Indoor or Outdoor Design

The compact black enclosure can be installed indoors or outdoors and is suitable for either wall or post mounting.

With an IP54 ingress-protection rating and an IK08 impact rating, it is designed to withstand everyday outdoor conditions.

📋 Technical Specifications

• Product: Ohme ePod
• Order code: OHMEX1GB003-BL
• Charging output: Up to 7.4kW
• Maximum current: 32A
• Nominal supply: 230V AC
• Frequency: 50/60Hz
• Supply: Single phase
• Supply connections: L + N + E, 6mm²
• Charging mode: Mode 3
• Socket: Type 2 to IEC 62196
• Connectivity: Integrated 3G/4G multinetwork SIM
• Control: Ohme app or three onboard buttons
• Load management: Dynamic load balancing with optional CT clamp
• Status indicator: Five-colour LED strip
• Ingress protection: IP54
• Impact resistance: IK08
• Operating temperature: -25°C to +45°C
• Operating humidity: 5–95% RH
• Dimensions: 230mm × 140mm × 100mm
• Unit weight: 1.5kg
• Colour: Black
• Installation: Indoor or outdoor, wall or post mounted
• Cable entry: Rear or underside
• Maximum conductor size: 6mm²

✅ Key Benefits

• ⚡ Up to 7.4kW charging
• 🚗 Suitable for virtually any Type 2 EV
• 💷 Charges around cheaper electricity periods
• 📱 Full control through the Ohme app
• 📶 Built-in 3G/4G connectivity
• 🏠 No home Wi-Fi connection required
• 🔌 Flexible socketed design
• 📏 Compact and discreet enclosure
• 🛡️ Integrated RCD, DC leakage and PEN protection
• 🔄 Automatic over-the-air updates
• 🇬🇧 UK Smart Charging Regulations 2021 compliant
• ✅ UKCA marked
