Live LSMC14M-SP 14 Way (11 Usable Way) Metal Clad Surge Protection Consumer Unit 100A Main Switch
Live LSMC14M-SP 14 Way (11 Usable Way) Metal Clad Surge Protection Consumer Unit 100A Main Switch is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Delivery and Shipping
Delivery and Shipping
FREE Delivery (UK Mainland) on Orders Over £70, £5.99 Delivery (UK Mainland) under £70.
Live LSMC14M-SP 14 Way (11 Usable Way) Metal Clad Surge Protection ...
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Fully Metal Enclosure
BS 7671 Amendment 3 compliant. Non-combustible construction for domestic and commercial use.
20/40kA DP SPD Included
Surge protection pre-fitted. Satisfies BS 7671 Amendment 2 SPD requirement in one unit.
9 Type A RCBOs Pre-loaded
Ready to connect. All RCBOs are Type A 30mA B Curve for full regulatory compliance.
11 Useable Ways
9 ways populated, 2 free for additional circuits. 100A double pole main switch.
Consumer Unit
What the LSMC14M-SP Is and What It Includes
The Live Electrical LSMC14M-SP is a fully metal consumer unit with 11 useable circuit ways, pre-populated with 9 Type A 30mA RCBOs, a pre-fitted 20/40kA double pole SPD and a 100A double pole main switch. At £124.71 + VAT it is a complete consumer unit package ready for connection: no separate SPD purchase, no separate RCBO fitting, no missing devices to source before the board goes live.
The metal construction satisfies the BS 7671:2018 Amendment 3 requirement for non-combustible consumer unit enclosures in domestic premises. The pre-fitted SPD satisfies the Amendment 2 requirement for surge protection in most new domestic and commercial installations. The pre-loaded RCBOs are Type A, meaning they detect both sinusoidal AC and pulsating DC earth fault currents - the correct specification for modern installations including EV charger circuits and circuits with electronic loads.
The enclosure measures 316mm (W) x 270mm (H) x 110mm (D), finished in white RAL 9010 powder coat. Circular cable entry knockouts are provided at the top and bottom. An earth terminal bar is pre-fitted. A tails gland and grommet strip are included. Two of the 11 useable ways are fitted with blank fillers, leaving two free ways for additional devices where the installation design requires them.
Full Kit Contents
What Comes Pre-Fitted in the LSMC14M-SP
Everything is pre-installed. The consumer unit arrives with main switch, SPD and all 9 RCBOs in place.
| QUANTITY & PART | RATING |
|---|---|
| 1x 100A Double Pole Main Switch | 100A DP |
| 1x Double Pole Surge Protection Device | 20/40kA DP SPD |
| 3x AMR106B-030 Type A RCBO | 6A B Curve 30mA |
| 2x AMR116B-030 Type A RCBO | 16A B Curve 30mA |
| 1x AMR120B-030 Type A RCBO | 20A B Curve 30mA |
| 2x AMR132B-030 Type A RCBO | 32A B Curve 30mA |
| 1x AMR140B-030 Type A RCBO | 40A B Curve 30mA |
| 2x Blank Fillers (free ways) | Available for additional devices |
| Earth terminal bar (pre-fitted) + Tails gland & grommet strip | Included |
The two free ways can be populated with additional Live Electrical AMR B-030 Type A RCBOs from the Harbro range where the circuit design requires additional circuits beyond the nine pre-installed.
Regulatory Compliance
Metal Construction and SPD: Why Both Are Now Required
Why a metal consumer unit?
BS 7671:2018 Amendment 3 requires consumer units installed in domestic premises to have enclosures manufactured from non-combustible material. This requirement followed evidence that arc faults developing inside plastic consumer unit enclosures had contributed to house fires, with the plastic enclosure allowing fire to spread rather than containing it. A metal enclosure contains any arc fault within the board. The LSMC14M-SP is fully metal construction throughout - enclosure, drop-down cover and lid.
Why an SPD?
BS 7671:2018 Amendment 2 (2022) requires surge protection devices in most new electrical installations where the consequences of equipment damage from a transient overvoltage would exceed the cost of the SPD. In practice this covers the majority of new domestic and commercial installations where electronic equipment, connected devices and EV charging infrastructure are present. A 20/40kA double pole Type 2 SPD satisfies this requirement. Having the SPD pre-fitted in the consumer unit removes the need for a separate purchase and ensures the SPD is installed correctly in relation to the main incoming supply.
Why Type A RCBOs rather than Type AC?
All nine pre-installed RCBOs are Type A, which detects both sinusoidal AC and pulsating DC earth fault currents. Modern electronic loads including EV chargers, PV inverters, LED drivers and switch-mode power supplies can produce pulsating DC fault currents during an earth fault. BS 7671:2018 Amendment 2 requires Type A protection for circuits supplying such equipment. Using Type A RCBOs throughout the board future-proofs the installation against the growing prevalence of electronic loads on domestic circuits.
Consumer Unit Comparison
Pre-Populated vs Empty Consumer Unit: What to Consider
The LSMC14M-SP suits installs where the pre-loaded circuit mix matches the design. For installs requiring a specific custom configuration, individual devices can be sourced separately.
| Factor | LSMC14M-SP (pre-populated) | Empty metal enclosure + individual devices |
|---|---|---|
| On-site time | RCBOs pre-fitted - connect tails and circuits | Fit devices individually on site |
| SPD | 20/40kA DP SPD pre-installed | Purchase and fit separately |
| RCBO type | Type A (pulsating DC detection) throughout | Installer specifies per device |
| Circuit flexibility | Pre-set mix (6A x3, 16A x2, 20A x1, 32A x2, 40A x1) + 2 free ways | Fully configurable to design specification |
| Metal enclosure | Yes - BS 7671 Amendment 3 compliant | Must specify metal (avoid plastic for domestic) |
| Best for | Standard domestic installation where RCBO mix matches the design; time-efficient single-order solution | Installs requiring a specific custom RCBO configuration or unusual circuit mix |
Volume pricing and trade account enquiries
Call the Peterlee trade counter on 0191 518 1998 or email sales@harbroelectrical.co.uk for pricing on multi-unit orders, project quantities and ongoing contractor supply. We supply electrical contractors across Peterlee, Hartlepool, Sunderland, Durham and Seaham.
Technical Specifications
LSMC14M-SP Full Specification
| Model | LSMC14M-SP |
| Type | Metal consumer unit, pre-populated, with SPD |
| Total ways | 14-way enclosure |
| Useable ways | 11 ways |
| Pre-installed devices | 9 x Type A RCBOs + 20/40kA DP SPD (2 free ways) |
| Main switch | 100A Double Pole (DP) |
| SPD | 20/40kA DP Surge Protection Device (pre-fitted) |
| RCBO type | Type A, B Curve, 30mA, Live Electrical AMR B-030 |
| RCBO configuration | 3 x 6A, 2 x 16A, 1 x 20A, 2 x 32A, 1 x 40A |
| Enclosure material | Fully metal, drop-down cover and lid |
| Finish | White polyester powder coat, RAL 9010 |
| Width | 316mm |
| Height | 270mm |
| Depth | 110mm |
| Cable entry | Circular knockouts, top and bottom |
| Included accessories | Earth terminal bar (pre-fitted), tails gland and grommet strip |
| Suitable for | Residential and commercial installations |
| Trade price at Harbro | £48.50 + VAT (£58.20) |
Frequently Asked
LSMC14M-SP Consumer Unit: Common Questions
What is a consumer unit?
A consumer unit (also called a fuse box or distribution board) is the main electrical distribution point in a building. It contains the main switch, which isolates the entire installation, the surge protection device, and the individual circuit protective devices - RCBOs, MCBs or RCDs - for each circuit. The LSMC14M-SP is a 14-way metal consumer unit with a 100A double pole main switch, 20/40kA DP SPD and 9 pre-populated Type A 30mA B Curve RCBOs covering 9 of the 11 useable circuit ways, with 2 free ways for additional circuits.
Why is a metal consumer unit required for domestic installations?
BS 7671:2018 Amendment 3 requires consumer units in domestic premises to use non-combustible (metal) enclosures. The requirement followed evidence that arc faults inside plastic consumer unit enclosures contributed to house fires, with the plastic casing allowing fire to spread rather than containing it. A metal enclosure contains any arc fault within the board. The LSMC14M-SP meets this requirement with a fully metal enclosure, drop-down cover and lid throughout. This is the mandatory specification for all new consumer unit installations in domestic dwellings in England, Wales and Scotland.
What is a Surge Protection Device (SPD) and why is it included?
A Surge Protection Device (SPD) protects the installation and connected equipment against transient overvoltages caused by nearby lightning strikes, mains switching and other supply events. The 20/40kA double pole SPD pre-fitted in the LSMC14M-SP is a Type 2 (coordinated with the incoming supply) device. BS 7671:2018 Amendment 2 requires SPDs in most new electrical installations where the expected damage from transient overvoltages would exceed the cost of protection. Having the SPD pre-installed in the consumer unit removes the need for a separate device and ensures it is correctly positioned at the point of supply.
What RCBOs are pre-installed in the LSMC14M-SP?
Nine Live Electrical Type A 30mA B Curve RCBOs: 3 x AMR106B-030 (6A), 2 x AMR116B-030 (16A), 1 x AMR120B-030 (20A), 2 x AMR132B-030 (32A) and 1 x AMR140B-030 (40A). Two of the 11 useable ways are fitted with blank fillers. All RCBOs are Type A, which detects both sinusoidal AC and pulsating DC earth fault currents - the specification required for EV charger circuits and circuits with electronic loads under BS 7671 Amendment 2.
Can I add more RCBOs to the LSMC14M-SP?
Yes. The two blank ways accept additional Live Electrical AMR B-030 Type A RCBOs in any available amperage - 6A, 10A, 16A, 20A, 32A or 40A. The pre-installed RCBOs can also be swapped for different amperages if the installation design requires a different circuit configuration. All Live Electrical AMR B-030 RCBOs are available individually from Harbro at £8.19 + VAT per device.
What does DP mean on the main switch and SPD?
DP stands for double pole. A double pole device switches both the line and neutral conductors simultaneously. A double pole main switch fully isolates both conductors when operated, which is the required configuration for consumer unit main isolators under BS 7671. The double pole SPD provides surge protection across both line and neutral. Some older consumer units use single pole main switches, which leave the neutral conductor connected during isolation - not the current compliant specification for new installations.
Does the LSMC14M-SP need to be installed by an electrician?
Yes. Consumer unit installation involves connection to the mains supply tails and is notifiable work under Part P of the Building Regulations in England and Wales. It must be carried out by a qualified electrician registered with a competent person scheme (NICEIC, NAPIT, ELECSA or equivalent), or notified to the local building control authority. This is a trade product available from Harbro Electrical to qualified electricians and contractors. It is not a consumer product.
Where can I buy consumer units in the North East?
The Live Electrical LSMC14M-SP consumer unit and the full Live Electrical and FuseBox range are stocked at Harbro Electrical, 5 & 6 Whitworth Road, Peterlee, Co Durham, SR8 2LY. Mon to Thu 7:30am to 5:00pm, Fri 7:30am to 4:00pm, Sat 8:30am to 12:30pm. Call 0191 518 1998 to check current stock. We supply electrical contractors across Peterlee, Hartlepool, Sunderland, Durham and Seaham. Free UK Mainland delivery on orders over £70.
